Full-scale model static tests of integral joint on the Shiziyang Bridge
Article Text (Baidu Translation)
-
摘要: 为研究板桁结合钢桁加劲梁整体节点面外转动行为，评估狮子洋大桥加劲梁整体节点在设计荷载作用下的结构安全性，开展整体节点足尺模型静载试验；建立狮子洋大桥全桥有限元模型以确定试验荷载大小，并利用加劲梁节段与节点有限元模型确定了应变与变形测点；试验测试了面外受力状态下节点横梁、腹杆与弦杆的截面正应力；基于薄壁结构应力分析理论，提取了横梁与腹杆的弯曲正应力，依此计算面外弯矩并验证了该方法的准确性；测试了节点面外转动变形，绘制节点面外转动的弯矩转角曲线，获取了节点面外转动刚度；利用弦杆截面实测正应力提取了弦杆约束扭转正应力，评估了弦杆的抗扭性能；测试了节点局部区域三向应力并计算各测点的Mises应力，评估节点在面外静载作用下的安全性。试验结果表明：节点在设计荷载作用下始终保持弹性状态，采用提出的方法分析截面正应力求解所得的截面面外弯矩与理论值吻合良好，相对误差为2.5%~10.0%；面外荷载作用下，横梁与腹杆截面剪力滞效应明显，横梁顶板有效宽度折减40%，腹杆翼板有效宽度折减10%；狮子洋大桥加劲梁整体节点面外转动刚度介于刚接与铰接之间，转动刚度受边界条件影响较大；弦杆最大约束扭转正应力为设计活载下的弦杆轴力应力的4.19%；节点面外受力最不利位置为弦杆横隔板过焊孔，Mises应力小于钢材的设计强度，安全系数为2.32。试验结果与提出的计算方法可为钢桁梁节点面外受力性能研究提供参考。Abstract: In order to study the out-of-plane rotational behavior of the integral joint of the plate-truss composite steel truss stiffening girder and evaluate the structural safety of the integral joint of the Shiziyang Bridge under the design load, a full-scale model static load test of the integral joint was carried out. The finite element model of Shiziyang Bridge was established to determine the magnitude of the test load, and the finite element model of the stiffening girder segment and joint was used to determine the strain and deformation measurement points. The sectional normal stresses of the crossbeam, web members, and chord of the joint under out-of-plane loading were measured. Based on the stress analysis theory of thin-walled structures, the bending normal stresses of the crossbeam and web members were extracted. The out-of-plane bending moments were calculated, and the accuracy of this method was verified. The out-of-plane rotational deformation of the joint was tested. The out-of-plane moment rotation curve of the joint was plotted, and the out-of-plane rotational stiffness of the joint was obtained. The restrained torsional normal stress of the chord was extracted using the measured sectional normal stress, and the torsional performance of the chord was evaluated. The three-dimensional stress of the local areas of the joint was tested, and the Mises stresses at each measurement point were calculated to evaluate the safety of the joint under out-of-plane static load. Test results show that the joint remains in the elastic stage under the design load. The out-of-plane bending moment calculated by this method based on sectional normal stress analysis agrees well with the theoretical value, with a relative error ranging from 2.5% to 10.0%. Under out-of-plane load, obvious shear lag effects are observed in the crossbeam and web member sections, with a 40% reduction in the effective width of the top flange of the crossbeam and a 10% reduction in the effective width of the flanges of web members. The out-of-plane rotational stiffness of the integral joint of Shiziyang Bridge is between that of a rigid joint and a hinged joint and is significantly influenced by boundary conditions. The maximum restrained torsional normal stress of the chord is 4.19% of the axial stress under design live load. The most unfavorable stress position under out-of-plane load is at the welding hole of the chord diaphragm where the Mises stress is lower than the design strength of steel, with a safety factor of 2.32. The test results and the proposed calculation method can serve as a reference for the study of the out-of-plane mechanical behavior of steel truss girder joints.
-
图 7 节点板三向应力测点(单位: mm)
Figure 7. Measurement points for three-dimensional stress of gusset plate (unit: mm)
图 15 腹杆翼板面外弯曲正应力
Figure 15. Out-of-plane bending normal stresses of flanges for web members
图 19 弦杆约束扭转正应力(单位：MPa)
Figure 19. Constrained torsional normal stresses of chord (unit: MPa)
表 1 试件尺寸
Table 1. Dimensions of specimen
构件 杆件长度/mm 截面高度/mm 截面宽度/mm 弦杆 9 600 1 700 1 000 腹杆 4 500 1 000 800 节点横梁 6 000 1 700~2 361 3 200
下载: 导出CSV
表 2 钢材材料特性
Table 2. Material properties of steel
类型 材料牌号 板厚/mm 屈服强度/MPa 抗拉强度/MPa 弹性模量/MPa 节点板、腹杆翼板、横隔板 Q420D 28 451 597 205 800 弦杆加厚顶底板 24 492 575 201 000 腹杆腹板 22 480 567 202 000 弦杆腹板、腹杆加劲板 20 478 570 211 100 弦杆顶底板、腹板加劲肋 18 491 586 200 300 横隔板 14 476 596 201 500 弦杆加劲肋、横隔肋 10 463 593 209 500 节点横梁下翼板 Q355D 28 436 521 204 600 U肋加劲桥面板 18 470 551 210 500 板肋加劲桥面板 16 424 544 210 800 节点横梁腹板、板肋 14 430 590 191 200 节点横梁腹板加劲肋 10 477 550 210 100 桥面系U肋 8 439 549 195 400
下载: 导出CSV
表 3 试件测试内容
Table 3. Test contents of specimen
加载工况 边界条件 加载位置 单点荷载/kN 测试内容 1 弦杆两端固接，腹杆水平约束 横梁自由端桥面板 600 横梁节点转动刚度 2 弦杆两端固接，腹杆水平自由 横梁自由端桥面板 350 3 弦杆两端固接，横梁竖向约束 腹杆自由端外侧翼板 350 腹杆节点转动刚度、弦杆约束扭转正应力、节点局部受力 4 弦杆两端固接，横梁竖向自由 腹杆自由端外侧翼板 350 腹杆节点转动刚度
下载: 导出CSV
表 4 腹杆翼板有效宽度
加载工况 腹杆 板件 测试截面 等效应力/MPa 有效宽度/mm 宽度折减/% 3 腹杆1 内侧翼板 截面1 -27.12 780 -2.50 外侧翼板 截面2 -9.76 775 -3.13 内侧翼板 截面1 30.96 746 -6.75 外侧翼板 截面2 24.04 717 -10.38 腹杆2 内侧翼板 截面1 -22.03 799 -0.13 外侧翼板 截面2 -16.43 786 -1.75 内侧翼板 截面1 28.50 733 -8.38 外侧翼板 截面2 21.98 695 -13.13 4 腹杆1 内侧翼板 截面1 -25.79 787 -1.63 外侧翼板 截面2 -18.72 769 -3.88 内侧翼板 截面1 27.78 792 -1.00 外侧翼板 截面2 23.90 713 -10.88 腹杆2 内侧翼板 截面1 -21.59 799 -0.13 外侧翼板 截面2 -15.99 755 -5.63 内侧翼板 截面1 24.84 731 -8.63 外侧翼板 截面2 17.09 782 -2.25
下载: 导出CSV
表 5 弦杆约束扭转正应力
Table 5. Constrained torsional normal stresses of chord
测试截面 设计活载下轴力正应力/MPa 最大约束扭转正应力/MPa 比值/% 1 -204.2 -2.44 1.19 2 -204.2 -7.08 3.47 3 -204.2 -8.55 4.19 4 -204.2 -2.62 1.28
下载: 导出CSV
-
[1] JENNINGS A. Closure to "gravity stiffness of classical suspension bridges" by Alan Jennings (January, 1983)[J]. Journal of Structural Engineering, 1984, 110(4): 916-918. [2] OKAUCHI I, MIYATA T, TATSUMI M, et al. Dynamic field tests and studies on vibrational characteristics of long-span suspension bridges[J]. Japan Society of Civil Engineers, 1992(446): 101-112. [3] 高宗余, 史方华. 温州瓯江北口大桥主桥设计关键技术[J]. 桥梁建设, 2017, 47(1): 1-5.GAO Zong-yu, SHI Fang-hua. Key techniques of design of main bridge of Oujiang River North Estuary Bridge in Wenzhou[J]. Bridge Construction, 2017, 47(1): 1-5. [4] 张成东, 肖海珠, 徐恭义. 杨泗港长江大桥总体设计[J]. 桥梁建设, 2016, 46(2): 81-86.ZHANG Cheng-dong, XIAO Hai-zhu, XU Gong-yi. Overall design of Yangsigang Changjiang River Bridge[J]. Bridge Construction, 2016, 46(2): 81-86. [5] 郭峰超, 王茂强, 张太科. 超2 000 m级大跨桥梁结构体系研究[J]. 公路, 2022, 67(10): 194-198.GUO Feng-chao, WANG Mao-qiang, ZHANG Tai-ke. Study on structural system of long span bridge over 2 000 m class[J]. Highway, 2022, 67(10): 194-198. [6] 鲜荣, 唐茂林, 吴玲正, 等. 2 000 m级超大跨度悬索桥主缆架设影响参数研究[J]. 世界桥梁, 2023, 51(3): 74-80.XIAN Rong, TANG Mao-lin, WU Ling-zheng, et al. Research on main cable erection influential parameters of suspension bridge with span length over 2 000 m[J]. World Bridges, 2023, 51(3): 74-80. [7] TOUSIGNANT K, PACKER J A. Analysis of rectangular hollow section trusses[J]. Canadian Journal of Civil Engineering, 2019, 46: 160-175. [8] FRATER G S, PACKER J A. Modelling of hollow structural section trusses[J]. Canadian Journal of Civil Engineering, 1992, 19(6): 947-959. [9] GARIFULLIN M, BRONZOVA M, PAJUNEN S, et al. Initial axial stiffness of welded RHS T joints[J]. Journal of Constructional Steel Research, 2019, 153: 459-472. [10] 刘永健. 矩形钢管混凝土桁架节点极限承载力试验与设计方法研究[D]. 长沙: 湖南大学, 2003.LIU Yong-jian. Experiments on ultimate bearing capacity and research on design method of joints of concrete-filled rectangular steel tube truss[D]. Changsha: Hunan University, 2003. [11] 程高, 刘永健, 田智娟, 等. PBL加劲型矩形钢管混凝土不等宽T型节点受拉性能[J]. 长安大学学报(自然科学版), 2015, 35(3): 83-90.CHENG Gao, LIU Yong-jian, TIAN Zhi-juan, et al. Tensile behavior of PBL stiffened concrete-filled rectangular steel tubular unequal T-connections[J]. Journal of Chang'an University (Natural Science Edition), 2015, 35(3): 83-90. [12] 刘永健, 王文帅, 马印平, 等. 矩形钢管和矩形钢管混凝土T形不等宽受拉节点轴向刚度[J]. 建筑科学与工程学报, 2020, 37(1): 1-13.LIU Yong-jian, WANG Wen-shuai, MA Yin-ping, et al. Axial stiffness of RHS and CFRHS T-joints with unequal width subjected to tension[J]. Journal of Architecture and Civil Engineering, 2020, 37(1): 1-13. [13] PACKER J A. Concrete-filled HSS connections[J]. Journal of Structural Engineering, 1995, 121(3): 458-467. [14] LI H T, YOUNG B. Experimental investigation of concrete-filled high-strength steel tubular X joints[J]. Journal of Structural Engineering, 2018, 144(10): 04018178. [15] MA Y P, LIU Y J, WANG K, et al. Axial stiffness of concrete filled rectangular steel tubular (CFRST) truss joints[J]. Journal of Constructional Steel Research, 2021, 184(1): 106820. [16] MA Y P, LIU Y J, MA T Y, et al. Flexural stiffness of rectangular hollow section (RHS) trusses[J]. Engineering Structures, 2021, 239(5): 112336. [17] MA Y P, LIU Y J, WANG K, et al. Flexural behavior of concrete-filled rectangular steel tubular (CFRST) trusses[J]. Structures, 2022, 36(2): 32-49. [18] GARIFULLIN M, BRONZOVA M, JOKINEN T, et al. Effect of fillet welds on initial rotational stiffness of welded tubular joints[J]. Procedia Engineering, 2016, 165: 1643-1650. [19] GARIFULLIN M, PAJUNEN S, MELA K, et al. Initial in-plane rotational stiffness of welded RHS T joints with axial force in main member[J]. Journal of Constructional Steel Research, 2017, 139: 353-362. [20] HAVULA J, GARIFULLIN M, HEINISUO M, et al. Moment-rotation behavior of welded tubular high strength steel T joint[J]. Engineering Structures, 2018, 172: 523-537. [21] GARIFULLIN M, PAJUNEN S, MELA K, et al. Finite element model for rectangular hollow section T joints[J]. Rakenteiden Mekaniikka, 2018, DOI: 10.23998/RM.70439. [22] DE BARROS H T G D, DE OLIVEIRA M M D, SARMANHO A M C, et al. Stiffness assessment of welded Ⅰ-beam to RHS column connections[J]. Engineering structures, 2022, DOI: 10.1016/j.engstruct.2022.114661. [23] 赵必大, 赵滇生, 申屠倩芸, 等. 平面X形矩形钢管相贯节点平面外抗弯刚度[J]. 建筑结构学报, 2016, 37(增): 399-405.ZHAO Bi-da, ZHAO Dian-sheng, SHENTU Qian-yun, et al. Rigidity of unstiffened X-type RHS joints subjected to out-of-plane bending[J]. Journal of Building Structures, 2016, 37(S): 399-405. [24] 赵必大, 姜文澜, 柯珂, 等. 矩形钢管偏心相贯节点的平面外抗弯刚度[J]. 哈尔滨工程大学学报, 2019, 40(6): 1122-1127, 1133.ZHAO Bi-da, JIANG Wen-lan, KE Ke, et al. Out-of-plane flexural rigidity of unstiffened eccentric rectangular hollow section joints[J]. Journal of Harbin Engineering University, 2019, 40(6): 1122-1127, 1133. [25] 王天亮. 钢桁梁整体节点试验研究[J]. 桥梁建设, 1999(4): 32-40.WANG Tian-liang. Test study of integral panel points of steel truss girder[J]. Bridge Construction, 1999(4): 32-40. [26] 谭明鹤, 王荣辉, 黄永辉, 等. 刚性悬索加劲钢桁梁桥特殊节点模型试验[J]. 中国公路学报, 2008, 21(1): 47-52.TAN Ming-he, WANG Rong-hui, HUANG Yong-hui, et al. Special joint model test of stiff suspension reinforced steel truss bridge[J]. China Journal of Highway and Transport, 2008, 21(1): 47-52. [27] 谭明鹤, 王荣辉, 黄永辉. 刚性悬索加劲钢桁梁桥特殊节点模型试验设计与有限元分析[J]. 科学技术与工程, 2008(9): 2385-2391.TAN Ming-he, WANG Rong-hui, HUANG Yong-hui. Design and finite element analysis on special joint model test of rigid suspension stiffed steel truss bridge[J]. Science Technology and Engineering, 2008(9): 2385-2391. [28] WANG R H, HUANG Y H, LI Q S, et al. Model test and numerical analysis of a special joint for a truss bridge[J]. Journal of Constructional Steel Research, 2009, 65(6): 1261-1268. [29] 卫星. 郑州黄河公铁两用斜拉桥斜桁节点受力性能研究[J]. 铁道学报, 2011, 33(9): 89-93.WEI Xing. Mechanical behaviors of special joints of inclined trusses of the Zhengzhou Yellow River Highway-Railway Cable-Stayed Bridge[J]. Journal of the China Railway Society, 2011, 33(9): 89-93. [30] 刘昌永, 吴欣荣, 王玉银, 等. 多向拉压整体式钢桁梁节点静力试验研究[J]. 建筑结构学报, 2015, 36(增): 131-137.LIU Chang-yong, WU Xin-rong, WANG Yu-yin. Model test on an integral joint of steels truss bridge subjected to multi-directional loadings[J]. Journal of Building Structures, 2015, 36(S): 131-137. [31] 肖鑫, 潘永杰, 田越, 等. 超千米公铁两用斜拉桥关键节点模型试验[J]. 铁道建筑, 2015(10): 51-55.XIAO Xin, PAN Yong-jie, TIAN Yue, et al. Model test for key joints of extra-kilometer-span highway and railway shared cable-stayed bridge[J]. Railway Engineering, 2015(10): 51-55. [32] 魏思斯, 耿波, 尚军年, 等. 重庆曾家岩大桥多杆件特殊节点模型试验设计[J]. 公路交通技术, 2022, 38(6): 92-100, 107.WEI Si-si, GENG Bo, SHANG Jun-nian, et al. Design of model experiment on multi-member special joint of Chongqing Zengjiayan Bridge[J]. Journal of Highway and Transportation Research and Development, 2022, 38(6): 92-100, 107. [33] 魏思斯, 耿波, 尚军年, 等. 两桁悬索加劲钢桁梁桥特殊节点缩尺模型静载试验研究[J]. 桥梁建设, 2022, 52(5): 52-59.WEI Si-si, GENG Bo, SHANG Jun-nian, et al. Scaled static model test on special joints of two-main-truss stiff suspension reinforced steel truss bridge[J]. Bridge Construction, 2022, 52(5): 52-59. [34] 魏思斯, 耿波, 尚军年, 等. 板桁结合悬索加劲钢桁梁桥特殊节点受力行为[J]. 重庆交通大学学报(自然科学版), 2023, 42(1): 1-8.WEI Si-si, GENG Bo, SHANG Jun-nian, et al. Force behavior of special joints of plate-girder combined steel truss bridge reinforced by suspension cables[J]. Journal of Chongqing Jiaotong University (Natural Science), 2023, 42(1): 1-8. -
